Product details
- Forced mask wearing alert: If the recognizing face does not wear a mask, the device will prompt a voice reminder. At the same time, the authentication or attendance will be failed
- 7-inch LCD touch screen, 2 Mega pixel wide-angle lens, built-in M1 card reading module
- Face recognition distance (without face mask): 0.3 m to 3 m, Duration ＜ 0.2 s/User, Accuracy rate ≥ 99%
- Max. 50,000 faces capacity, Max. 5000 fingerprints capacity, and Max. 50,000 cards
- Two-way audio with client software,indoor station, and main station
- Supports TCP/IP,Wi-Fi
- Configuration via the web client
- Supports ISAPI and ISUP5.0 protocol
- IP65
| Specification | |
| System | |
| Operation System | Linux |
| FOV | HFOV = 46°; VFOV = 87° |
| Display | |
| Dimensions | 7-inch |
| Type | LCD |
| Operation Method | Capacitive touch screen |
| Video | |
| Pixel | 2 MP |
| Lens | 2 |
| Audio | |
| Tone Quality | Noise suppression and echo cancellation |
| Network | |
| Wired Network | 10 M/100 M/1000 M self-adaptive |
| Wi-Fi | Supported |
| Interfaces | |
| Network Interface | 1 |
| RS-485 | 1 |
| Wiegand | 1 |
| Lock Output | 1 |
| Exit Button | 1 |
| Door Contact Input | 1 |
| IO Input | 2 |
| IO Output | 1 |
| Power Interface | 2-pin connector |
| TAMPER | 1 |
| USB | 2 |
| Capacity | |
| Card Capacity | 50,000 |
| Face Capacity | 50,000 |
| Fingerprint Capacity | 5,000 |
| Event Capacity | 100,000 |
| Authentication | |
| Card Type | M1 card |
| Card Reading Frequency | 13.56 MHz |
| Card Reading Distance | 0 to 5 cm |
| Face Recognition Duration | < 0.2 s per person |
| Face Recognition Accuracy | ≥ 99% |
| Face Recognition Distance | 0.3 to 3 m (Without face mask) |
| General | |
| Power Supply Method | 2-pin connector |
| Power Supply | 12 VDC / 2 A |
| Working Temperature | -30 ℃ to 60 ℃ (-22 °F to 140 °F) |
| Working Humidity | 10 to 90% (No condensing) |
| Dimensions | 290 mm × 116.5 mm × 33 mm (11.4″ × 4.6″ × 1.3″) |
| Protective Level | IP65 |
| Installation | Wall mounting |
| Language | English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil) |
| Platform | Hik-ProConnect and HikCentral Professional |
| Function | |
| Face Anti-Spoofing | Supported |
| Advertisement | Supported |
| Audio Prompt | Supported |
| Time Synchronization | Supported |
